Figure 7


Download original image

Theoretical simulation on Zn microelectrodes. (A) The simulations of potential, electric field distribution, and energy distribution of (top) concentric circle structured, (middle) straight interdigital, and (down) circular Zn-PANI microbatteries [79]. (B) FEA of a nonplanar 3D-printed electrode and a conventional 2D sheet-type electrode on non-developable surfaces. The left scheme depicts the non-developable surface with non-zero Gaussian curvature [71]. (C) Optical images (up) and corresponding strain maps in the stretching direction (down) of an interdigitated current collector under different global tensile strains. The contour of the current collector at 0% strain is shown in the dashed line [101]. Reproduced with permission.
